DDS-1702 Portable Conductivity Meter
DDS-1702 Portable Conductivity Meter is an instrument used for the measurement of the conductivity of aqueous solution in the laboratory. It is widely used in petrochemical industry, bio-medicine, sewage treatment, environmental monitoring, mining and smelting and other industries as well as junior college institutions and research institutes. If equipped with conductivity electrode with the appropriate constant, it can also be used to measure the conductivity of pure water or ultra-pure water in electronic semiconductor or nuclear power industry and power plants.
Technical Indexes
DDS-1702 Portable Conductivity Meter is an instrument used for the measurement of the conductivity of aqueous solution in the laboratory. It is widely used in petrochemical industry, bio-medicine, sewage treatment, environmental monitoring, mining and smelting and other industries as well as junior college institutions and research institutes. If equipped with conductivity electrode with the appropriate constant, it can also be used to measure the conductivity of pure water or ultra-pure water in electronic semiconductor or nuclear power industry and power plants.
Technical Indexes
| Measure Range | Conductivity | 0.00 μS/cm…199.9 mS/cm |
| TDS | 0.1 mg/L … 199.9 g/L | |
| Salinity | 0.0 ppt…80.0 ppt | |
| Resistivity | 0Ω.cm … 100MΩ.cm | |
| Temperature(ATC/MTC) | -5…105 ºC | |
| Resolution | Conductivity / TDS / salinity / resistivity | Automatic sorting |
| Temperature | 0.1ºC | |
| Electronic unit error | Conductivity | ±0.5 % FS |
| Temperature | ±0.3 ºC | |
| Calibration | 1 point 9 preset standards (Europe and America, China , Japan) | |
| Data storage | Calibration data 99 measurement data | |
| Power requirements | 4xAA/LR6(No. 5 battery) | |
| Monitor | LED monitor | |
| Shell | ABS | |
